Mid Hinged Lattice Towers

Get a Price/Quote

Product Details:

Product Type Mid Hinged Lattice Tower
Material Mild Steel / Galvanized Steel
Welding Standard IS 9595 or AWS D1.1
Capacity As per Design Specification
Application Lighting, CCTV, Communication, Power Distribution
Galvanization Standard IS 2629 / IS 4759, or as per customer requirement
Out Coating Hot Dip Galvanized
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mid Hinged Lattice Towers Price And Quantity

Minimum Order Quantity 1 Piece

Installation Location Outdoor / Open Field / Roadside
Hinge Type Mid-Hinged Foldable Structure with Locking Mechanism
Packing Knocked Down for Easy Transportation
Wind Speed Resistance Designed for Wind Speed Upto 180 km/h
Foundation Type Grouted or Flanged Base
Maintenance Access Integrated Ladder and Safety Cage Option
Assembly Method On-site Modular Assembly
Corrosion Protection Life Up to 25 Years (Depending on Environment)
Weight Varies with Height and Design
Connection Method Bolted Joint Construction
Customization Available as per Project Requirement
Accessories Available with Luminaire Mounts, Antenna Brackets, Safety Devices
Anchor Bolt Material High Strength Galvanized Steel

Mid Hinged Lattice Towers Product Specifications

Shape Lattice Structure
Material Mild Steel / Galvanized Steel
Color Silver or Customized
Capacity As per Design Specification
Surface Treatment Corrosion Resistant Coating
Product Type Mid Hinged Lattice Tower
Standard IEC, IS or as per User Specification
Out Coating Hot Dip Galvanized
Application Lighting, CCTV, Communication, Power Distribution
Voltage Upto 33 kV
Height 9 Meter - 30 Meter (Customizable)
Thickness 3 mm - 8 mm or as specified
Welding Standard IS 9595 or AWS D1.1
Design Modular Prefabricated Segments
Galvanization Standard IS 2629 / IS 4759, or as per customer requirement

Installation Location Outdoor / Open Field / Roadside
Hinge Type Mid-Hinged Foldable Structure with Locking Mechanism
Packing Knocked Down for Easy Transportation
Wind Speed Resistance Designed for Wind Speed Upto 180 km/h
Foundation Type Grouted or Flanged Base
Maintenance Access Integrated Ladder and Safety Cage Option
Assembly Method On-site Modular Assembly
Corrosion Protection Life Up to 25 Years (Depending on Environment)
Weight Varies with Height and Design
Connection Method Bolted Joint Construction
Customization Available as per Project Requirement
Accessories Available with Luminaire Mounts, Antenna Brackets, Safety Devices
Anchor Bolt Material High Strength Galvanized Steel

Mid Hinged Lattice Towers Trade Information

FOB Port delhi
Payment Terms Cash in Advance (CID), Cheque
Supply Ability 1 Piece Per Week
Delivery Time 1 Week
Main Domestic Market , All India

Product Description

Mid Hinged Lattice Towers Description

Mid hinged lattice towers are structures with a lattice design and a hinge mechanism located at a midpoint, allowing for easy access, maintenance, or lowering of the tower. Key features include:

Lattice design: Provides strength, stability, and flexibility.

Midpoint hinge: Enables easy lowering or raising of the tower for maintenance or repairs.

Versatility: Suitable for various applications, including telecommunications, lighting, or surveillance.

These towers offer a combination of structural strength and convenient access.
